Elephant Robotics

Elephant Mecharm

€845,27

Sale Sold out

net

The Elephant Robotics mechArm 270 is an innovative series of miniature 6-axis collaborative robots that stands out from other models thanks to its unique, fully symmetrical (centrosymmetric) design. This allows the device to faithfully replicate the kinematics and mechanics of full-scale, heavy-duty industrial robots within a compact, desktop-friendly format. Offering a choice between two popular control architectures—Raspberry Pi and M5Stack—the mechArm platform serves as an excellent, versatile tool for education, prototyping modern production lines, and testing advanced algorithms, all without the need to invest in large-scale equipment.

View full details

mecharm

Symmetrical industrial design

Unlike standard cobots with an asymmetric structure, the mechArm has a centrally positioned center of gravity. This architecture faithfully simulates the operation of classic industrial robots, which is extremely useful when learning precise inverse kinematics, calculating trajectories, and simulating mass distribution.

mecharm

6 degrees of freedom and high agility

Despite its light weight (approx. 1 kg), the robot offers full, six-axis freedom of movement. It has an operating reach of 270 mm and a payload of up to 250 g, which allows for the execution of complex manipulation tasks from any angle.

Drag & Teach

Rapid deployment

Similar to large collaborative robots, mechArm enables programming through physical guidance of the arm. The user manually moves the end-effector to consecutive points, and the system records them, allowing for immediate, automated reproduction of the plotted path.
